Spindle motor&CNC router

Spindle motor&CNC router

Operating environment: 0 ℃ -55 ℃

Polar logarithm: 4

Incremental encoder cable: 2500/1024PPR

Humidity less than: 90%

Absolute level: F

Protection level: IP54

Insulation and withstand voltage: AC1500V, 1 minute

Insulation resistance: DC500V, above 10M Ω

Structure: air-cooled

Working system: continuous

Installation method: flange/horizontal installation

Power：1.5~9KW | Power:220/380V

speed：12000~24000rpm

Product details

Deep communication, only for deeper cooperation

Your trust and support are the biggest driving force for us to move forward

Related recommendations

40 Series servo motor

Pair of Poles：5 | Power：50~100W

speed：5000rpm | voltage：220V

60 Series Servo motor

Pair of Poles：5 | Power：200~400W

speed：5000rpm | voltage：220V

110 Series Servo motor

Pair of Poles：5 | Power：0.6~2.0KW

speed：2000~3000rpm

80 Series Servo motor

Pair of Poles：5 | Power：400~1000W

speed：5000rpm | voltage：220V

90 Series Servo motor

Pair of Poles：5 | Power：750~1000W

speed：5000rpm | voltage：220V

130 Series Servo motor

Pair of Poles：5 | Power：1~3.8KW

speed：1000~2500rpm
